EFS-3000 Big Pond/Lake Fountain 22'H x 30'W sprays

      PLEASE CALL 1-800-351-8814 to order the EFS3000 UNLIGHTED FOUNTAIN

The EFS-3000 unlighted fountain is for big ponds and provides a large 22'H x 30'W fountain display in a 3 tiered, fanjet or trumpet pattern. The EFS-3000 fountain design is built using a combination of 3 each 1hp high volume submersible trash pumps mounted on a single float platform. Our EFS-3000 fountain is intended for use in natural and man made retention ponds from 2 to 3+ acres where maximum visibility and water aeration is required. The EFS-3000 is available for 230 volt, single phase hookup only. The EFS-3000 fountain comes 100% assembled and is ready to install and operate right off the shipping skid.  Please call Bill to discuss your application.

EFS3000 pumps:

The EFS-3000 is supplied with 3 each 1hp, 230v, 1ph high volume submersible trash pumps. Our trash pumps have 3 sets of seals instead of 1 set of seals like ordinary clean water pumps have. The 2 sets of internal silicon carbide face seals and 1 outboard set of lip seals in the pump is why the pumps last so long. Our trash pumps are not the cheapest pumps out there but they are likely the best pumps being supplied on any retention pond fountain available today.

EFS3000 Spray Heads:

The EFS-3000 includes 3 sets of spray heads (9 heads total) in 3 tiered, fanjet and trumpet patterns.

Additional underwater service cord:

Additional service cord is available on the EFS-3000 up to a max of 300', see details below.

Optional GFCI Service Disconnect:

You can add a 30 amp GFCI protected service disconnect option for the EFS-3000 at an additional charge of $240 by selecting "YES" for the GFCI in your cart. If you select NO then install a 30 amp GFCI breaker ahead of our control panel.

EFS-3000 General Features:

Our EFS-3000 severe duty fountain is for lakes and big ponds from 2 to 3 acres. The fountain has a spray size of 22'H X 30'W sprays in a 3 -tier, fan-jet or trumpet pattern and is built using 3 each 1hp, 230 volt, 1ph, 60hz  high volume trash pumps rated at a combined total of 250GPM. The EFS-3000 fountain is available only in a 230 volt model and it is rated 16.5FLA. The EFS-3000 is designed for severe duty applications in retention, drainage or newly dug ponds where sand & debris concentrations are high. The trash pumps we use contain two sets of silicon carbide face seals and an outboard set of lip seals, 3 sets of seals total, for the ultimate in service life when operating in dirty or sandy water conditions. The EFS-3000 is a big impressive fountain and it is built using only Industrial grade components which will be beyond your expectations. The EFS-3000 is comparable to other manufacturers $10,000+ fountains in the same size range. The fountain comes 100% assembled and all you do is float it and drop 2 anchors where you want it to stay, hook up the power and you're done. Installation for this fountain takes about an hour and no special tools are needed. The EFS-3000 fountain is shipped by freight carrier, fully assembled and it weighs approx 280lbs. The EFS-3000 comes complete with 3 each 1hp high volume trash pumps, 150' underwater service cord, 8 circuit Intermatic control panel, 3 sets of spray heads, float platform and bottom plate protector. Everything you need is included and the only modification available for this fountain is to extend the cord length if required.

Additional cord is available up to a max of 250'. (Additional service cord price will fluctuate due to changing market copper prices.) Please call to order this fountain with extra service cord length. LTL Freight is additional. Shipping weight approx 280 lbs.

If you have questions or need more info call Bill at 800-351-8814 to discuss your application.
